Markem-Imaje

Meet the

Lightjet Vector

Laser

The Lightjet Vector high-power CO2 laser has been designed for the most demanding production environments delivering permanent, consistent, high-quality coding on some of the most challenging substrates such as PE, PP plastics, glass and rubber. This 120 Watt version is the ideal solution for complex messages of up to five line applications at high production speeds. This vector technology equipped with its articulating arm and compact scanning printhead is well suited for applications in the beverage, pharmaceutical, cosmetic and personal care industries.

Main Benefits:

  • Capable of printing complex messages at high output rates (up to 1,000 products/minute) without requiring external cooling (no air, no water).
  • Ability to print in hot locations (up to 40°C) while maintaining consistent coding quality.
  • The proven reliability of the rofin diffusion-cooled CO2 slab laser. Thanks to its 120 watts of power, you can expect consistent quality coding even after several years of intense use.
  • Ease of integration within packaging lines (Premium Labelling Solutions machines) with the compact printhead and articulating arm offers up to 1.2 metres of reach.
  • Capable of printing on different types of glass, plastics and even on difficult-to-code labels (e.g. gold coated label).

Finance Options

Ease your cash flow with Pyrotec Finance. Our flexible finance plans allow you to acquire essential equipment now and pay over time, keeping your production lines moving.

Smart Integration

Streamline your operations with Pyrotec PackLink. This advanced software links with your equipment to deliver real-time data, enhancing productivity and minimising downtime.

More about the

Lightjet Vector

  • Level Expert
  • Machine Type Primary Coders & Labellers
  • Technology Laser
  • Printing Resolution N/A
  • Print Speed N/A
  • Application Height N/A

Substrates & Materials

Glass, Plastic, Rubber

Industries

Any Industry,

Print Features

  • Coding on stationary or moving products.
  • Marking in the direction of product movement or perpendicularly.
  • Line speed (max): 300 m/min (8 characters, 2 mm high).
  • Marking speed (max): 1 000 characters/sec.
  • Fixed and variable marking: text, dates, times, counters, logos.
  • Set of vectorized fonts, True Type compatible, Asian and Arabic characters, specific font for thin materials (PET).
  • Character height from 1 to 50 mm.
  • Vast choice of barcodes: Ean8, Ean13, uCPa, uPCE, Code 39, 2/5 interleaved, code 128 and 2D codes – Datamatrix, aZTEC, PDF417, rSS14.
  • Coding area (mm): 105 x 105/fd 150.

Options

  • Coding area and focal distance:
    • Lens 70 x 70/fd 100.
    • Lens 140 x 140/fd 200.
    • Lens 210 x 210/fd 300.
  • 7 knuckles articulated arm.

Lightjet Vector

Product Video
