Print features – U2-Mobile Specifications

• Mono-jet printhead
• G head (printing resolution: 71 dpi)
• Up to four lines of print
• Print speed: up to 4.4 m/s
• Font height from 5 to 24 dots
• Character height: from 1.8 to 8.7 mm
• Wide choice of characters (Latin, Arabic, Cyrillic, Greek, Japanese, Chinese, Hebrew, Korean)

Operations

• Message library (up to 100 messages)
• International operator/machine interface (choice of 31 languages)
• Large WYSIWYG backlit blue screen
• Integrated help for navigation and diagnostics
• Creation of logos directly on the operator/machine interface
• USB port
• M6′ ink circuit
• Jet Speed Control guarantees to mark quality
• Automatic selection of fonts, depending on print speed and printhead/object distance
• Possibility to choose ink types: quick-drying MEK-free and MEK, alcohol-based, color changing for the sterilisation process
• 2 sealed intelligent cartridges of 0.8 liters each
• Quick connect/disconnect of accessories (photocell, encoder, alarm)
• RS-232 connectivity

Other Characteristics

• Weight: 18.5 kg
• 2-meter flexible umbilical cable
• Stainless steel cabinet
• Dust/humidity protection rating: IP55
• No plant air required
• Operating temperature range: 0° to 40° C, depending on the ink used
• Humidity: 10% to 90% non-condensing
• Electrical power supply: 100 – 120 V or 200 – 240 V with automatic switching; frequency 50/60 Hz; power 34 W

Easy to Set-up

• Easy to install: Move and install it anywhere according to your needs thanks to its robust IP55 fully stainless steel design.
• Easy to design messages: Quickly create or upload your codes via the newly designed user interface and USB connection.
• Easy to run: Intuitive online guide to managing your coder daily on your own more efficiently.

Smart to Operate

• The M6’: A smart all-in-one ink circuit that runs for approximately 6000 hours
• Optimise your time and change your M6’ in less than 6 minutes – all on your own. No extra maintenance needed.
• Reduced total cost of Ownership: Reduce your additive consumption by 50% thanks to a latest-generation hydraulic system.
• Smart consumables with no set-up required: With its innovative cartridge system design, you’ll experience advanced consumable management.
• Smart in use: No import or export issues; Its standard-priced MEK-free ink facilitates supply, compliance and safety-related issues.
